Description
We guarantee all of our products against defective workmanship and faulty materials for 6 months from the date of purchase.
Technical Information
| Rated Input Voltage | AC 220 V ± 10% |
| Rated Input Current | 220A / 28V |
| Rated Input Power Capacity | 8 kW |
| Output Current Range (A) | 20 – 200 |
| Output Circuit Voltage (V) | 56 |
| Rated Duty Cycle(%) | 60 |
| Ar Force | 0 -100 |
| Power Effecenicy (%) | 85 |
| Power Factor (%) | 0.73 |
| Protection & Indulation Class | IP 21S H |
| Application Rod (mm) | 2.5 / 3.15 |
| MOS / IGBT | IGBT |
| Weight | 3.65 Kgs |
